AD-DC2EA212

Mabank drone capture · AD-DC2EA212

Name: Mabank drone capture · AD-DC2EA212
Creator: AerialDataset
Published: 2026-09-14
License: https://aerialdataset.com/licensing

Retained together in this scene: 400 source image files, camera-data files, point clouds, orthomosaics.

⌖ Mabank, Texas, United States Capture date: Sep 12, 2026 Standard photogrammetry

Reviewed scene previews and selected capture photographs. Previews are resized; licensed downloads contain the available full-resolution files.

400source photos

6data types

6.9 GBfile inventory

2.75 cmreported GSD

EVALUATE THE REPRESENTATIONS TOGETHER

What connects in this scene?

Source imagery

Image files listed

Inspect overlap, resolution, coverage and image identifiers.

Camera data

Camera-data files listed

Verify intrinsics, reconstructed poses and image mapping. File presence alone is not calibration.

3D geometry

Point cloud or mesh listed

Check coordinate units and reconstruction quality. Derived geometry is not independent ground truth.

These labels describe the retained inventory, not certified model readiness. Camera-data evaluation guide →

About this environment and capture

This scene from Mabank, Texas, United States contains 400 retained original drone photographs captured with a FC8482 camera, together with metadata, project bundles, camera data, point clouds, orthomosaics. Use the file inventory to compare the imagery and reconstruction products, and evaluate the available sample before requesting a license. The imagery provides overlapping observations of one scene; retained file counts do not imply unique ground coverage. Photogrammetric geometry and reported positioning estimates are not independent survey measurements. Commercial training, redistribution and production use require an appropriate written license.

Dataset compilation and curation: AerialDataset.

Retained scene representations

Counts and sizes reflect the files retained for this version.

Data type	Format	Files	Size
Source photos	JPEG	400	3.5 GB
Orthomosaics	GeoTIFF	1	1.7 GB
Point clouds	EPT ZIP · LAZ	2	8.7 MB
Camera data	GeoJSON · JSON	3	355.4 KB
Project bundles	ZIP	1	1.7 GB
Metadata	JSON	4	387.1 KB

Bundles may overlap with individual files. Storage totals are not unique ground coverage. Camera-data files may contain observations, calibration or reconstructed poses; inspect the sample and inventory for the exact contents.

Capture & geospatial details

Location: Mabank, Texas, United States
Capture date: September 12, 2026Source capture metadata
Camera: FC8482
Coordinate system: EPSG:32614
Reported ground sampling distance: 2.75 cmOrthomosaic pixel size; not independent source-camera GSD
Reported scene area: 74.01 hectaresOrthomosaic raster extent; includes no-data pixels, not a surveyed boundary
Public location precision: Approximate scene location
Scene coordinates: 32.37, -96.11

Processing & output quality

Ortho-focused. Ortho optimization: the orthomosaic defaults to usable; the point cloud is not recommended.

Orthomosaic: Usable
Point cloud: Not recommended

Review statuses describe visual usability, not measured accuracy, RTK positioning or survey certification. Unlisted outputs are not included.

Accuracy & appropriate use

Photogrammetric reconstruction. Geometry is derived from the source imagery. It is not independent ground-truth geometry.

Source-reported post-alignment horizontal error estimate: 3.2 m. This is not an independent checkpoint measurement.

Geometry is reconstructed from imagery and is not independently surveyed ground truth. Source-reported horizontal error estimate: 3.2 m; not an independent checkpoint measurement.

Evaluate the supplied data against your own accuracy, rights and performance requirements before use.
